Booster Carbon Compact
Compact grow light solution for smaller surfaces
Key features:
12 m2 turf lighting
Ideal for goal areas and localized turf treatment
DLS full spectrum LED control
Optional IR heaters
Carbon fiber structure and sleek design
Engineered and manufactured by Stogger
Booster Carbon Compact
The Stogger Booster Carbon Compact is specifically designed to treat small turf areas of up to 12 m². Despite its compact size, the system delivers a powerful and adjustable light spectrum for maximum flexibility and efficiency.
Available in both DLS full-spectrum LED and a combination of LED with infrared heating, the Booster Compact accelerates turf recovery after intensive use. It’s ideal for targeted applications, such as shaded areas or heavily worn zones, and is suitable for use in both warm and cold climates.
Available in both DLS full-spectrum LED and a combination of LED with infrared heating, the Booster Compact accelerates turf recovery after intensive use. It’s ideal for targeted applications, such as shaded areas or heavily worn zones, and is suitable for use in both warm and cold climates.
All features
Compact growlight solution
Rental possible
Lowest operational costs by using LED
10 year LED warranty
Easy to use, simple design
State of the art LED technology from Mechatronix
120% more light than a 1000 watt HPS SON-T for the same energy!
Full light spectrum control
Fast delivery
Up to 50% more energy efficient than competing LED systems
Innovative lens design result in more homogeneous grass growth
| Key specifications | Booster Carbon Compact | LED / LED + Heat |
|---|---|
| Average illumination level (PPFD) | 400 μmol/m2/s |
| Illumination directly under LED Fixture | 600 μmol/m2/s |
| Lighting footprint in operation | 12 m2 |
| Dimensions of the device (LxWxH) | 1.80m x 1,m x 1.6m |
| Weight | 35 kg |
| LED | 1 x 1248W MechaTronix Coolstack® MAX |
| Thermal | 1 x 1100W heater |
| Electrical socket | 1 x 16A/ 230V |
| Maximum power consumption | 1 x 3.4A on 400V/ 10.8A on 230V | Number of pins per socket | 5 (3 phase, Neutral, Earth) |
| Extension cable | Optional available |
| Voltage | 400 V/230V |
| Power LED without heating | 1.24 kW |
| Power LED with heating | 2.34 kW |
Booster Carbon Compact explained
Compact grow light solution for smaller surfaces
Booster Carbon Compact LED+Heat
LED or LED and Heat solution generate PAR light to enable the process of photosynthesis by which a plant produces the food material (carbohydrates) it needs to function, recover and stay healthy.
LED or LED and Heat solution generate PAR light to enable the process of photosynthesis by which a plant produces the food material (carbohydrates) it needs to function, recover and stay healthy.
Assembly and installation
The Booster Carbon Compact is delivered as a complete unit. Simply attach the stand, connect it to the electricity grid, and you are ready to start lighting the grass! We will provide you with the necessary knowledge to plan your lighting.
The Booster Carbon Compact is delivered as a complete unit. Simply attach the stand, connect it to the electricity grid, and you are ready to start lighting the grass! We will provide you with the necessary knowledge to plan your lighting.
Low weight, easy usage
Due to the aluminium frames and the low weight, the Booster Carbon Compact is easily maneuverable and replaceable by only 1 fieldmanager.
Due to the aluminium frames and the low weight, the Booster Carbon Compact is easily maneuverable and replaceable by only 1 fieldmanager.
Easy control
The control is easy and intuitive. Manual controls allow to put the Booster on and off. Wireless control using our monitoring tool, additionally allows for creating lighting time tables and dimming levels.
The control is easy and intuitive. Manual controls allow to put the Booster on and off. Wireless control using our monitoring tool, additionally allows for creating lighting time tables and dimming levels.
